Lighters Labeling Machine
This is Lighter Semi-Auto Labeling Machine is used for labeling the side of lighters ,  it's applied to label the self-adhesive label on
various shape lighters side,   small prismatic cell side and USB flash disk side , etc .
This machine is widely used in electrical , pharmacy, foodstuff, cosmetic and chemical etc industries.
Feature
1.Suitable for labeling all  various shape side of small prismatic objects .
2.Composed by main body, sending paper, receiving paper, automatically fix position .
3. All metal are made of 304 stainless steels with surface finishing and special treatment, so this machine’s  quality can be guaranteed.
4. Small size labeling machine, very easy to operate.
Specification
1.Label width: 10-90mm
2.Label length:10-90mm
3.Products Diameter:
Length: 20mm-120mm
Width: 20mm-100mm
Thickness: 0.2mm-50mm
4.Max Outside diameter of label roll: φ350mm
5.Inside diameter of label roll: φ40mm or φ76mm
6.Max Labeling speed: 30pcs /min
7.Accuracy of labeling:±0.5- 1 mm
8.Power: 220V/110V 50/60Hz    200 W
9.Air Pressure: 4- 6 bar  or  0.4 -0.6 Mpa
10.Machine Net Weihgt : 70KG

11.Machine Dimension: 1050mm x 420mm x 600 mm
