Grinding Wheel Automatic Labeling Machine
This machine is applied to label grinding wheel, emery wheel. It also can be used to labe optical
disk or other round disk shape products.

Feature
1.Adopt High stability German LEUZE labeling system, Panasonic PLC , Panasonic Signal transmission system.
operation is stable and high-speed
2.Using touch-screen control operating system, simple, practical, efficient;
3.Adopt variety shape of object in top labeling;
4.Screw adjustment to suppress body movements accurately;
5.Synchronization chain mechanism ensure labeling smooth and precise calibration;
6.Advanced technology of pneumatic coding system, print the batch number and expiry clearly.
7.Labeling transparent label without bubble and wrinkle

Specification
1.Label width: 20-130mm
2.Label length:20-120mm
3.Products size
Diameter: φ100mm-φ130mm
Height:1-180mm
4.Max Outside diameter of label roll: φ240mm
5.Inside diameter of label roll: φ76mm
6.Max Labeling speed: 80pcs /min
7.Accuracy of labeling:±0.5mm
8.Power: 220V/110V  50/60Hz    900W
9.Machine Net Weihgt : 180KG
10.Air Pressure: 0.4-0.6mpa or 4-6 bar

10.Machine Dimension: 2000mm x 800mm x 1350 mm
